| System Core | |
|---|---|
| Processor | Supports Intel® Core™ Ultra 200S series Processors (LGA 1851 socket), 35W and 65W TDP - Intel® Core™ Ultra 9 285/285T - Intel® Core™ Ultra 7 265/265T - Intel® Core™ Ultra 5 245/245T |
| Chipset | Intel® Q870 Platform Controller Hub (Nuvo-11006) Intel® H810 Platform Controller Hub (Nuvo-11002) |
| Graphics | Integrated Intel Xe LPG Graphics |
| AI Engine | Integrated neural processing unit |
| Memory | Up to 128GB non-ECC DDR5 6400 SDRAM (Dual SODIMM slots) |
| AMT | Supports Intel vPro/ AMT 16.0 (Nuvo-11006 only) |
| TPM | Supports dTPM 2.0 |
| I/O Interface | |
| Ethernet | 1x 2.5G Ethernet by I226-IT and 1x Gigabit Ethernet by I219-LM (Nuvo-11002E/ LP) with screw-lock 5x 2.5G Ethernet by I226-IT and 1x Gigabit Ethernet by I219-LM (Nuvo-11006E/ LP) with screw-lock 1x optional 10GBASE-T Ethernet (Nuvo-11006E/ LP) |
| PoE+ | Optional IEEE 802.3at PoE+ PSE for Port 3 ~ Port 6 100 W total power budget |
| USB | 8x USB 3.2 Gen2 ports (Nuvo-11006E/ LP) 2x USB 3.2 Gen2, 2x USB3.2 Gen1 and 4x USB2.0 ports (Nuvo-11002E/ LP) |
| Isolated DIO | 4-CH isolated DI and 4-CH isolated DO |
| Video Port | 1x HDMI™, supporting 3840 x 2160 resolution 2x DisplayPort, supporting 3840 x 2160 resolution |
| Serial Port | 2x software-programmable RS-232/ 422/ 485 ports (COM1/ 2) 2x 3-wire RS-232 ports (COM3/ 4) |
| Audio | 1x 3.5 mm jack for mic-in and speaker-out |
| Storage Interface | |
| M.2 NVMe | 1x M.2 2280 M key NVMe socket (PCIe Gen5x4) for NVMe SSD (Nuvo-11006E/ LP) |
| SATA HDD | 2x internal SATA port for 2.5” HDD/ SSD installation, supporting RAID 0/ 1(Nuvo-11000E) 1x hot-swappable 2.5" HDD tray (7mm HDD/ SSD) and 1x internal 2.5" SATA port, supporting RAID 0/ 1 (Nuvo-11000LP) |
| Internal Expansion Bus | |
| PCI Express | 1x PCIe x16 slot@Gen4, 16-lanes PCIe signals in Cassette (Nuvo-11002E/ 11006E) |
| Mini PCI Express | 2x full-size mini PCI Express socket |
| Expandable I/O | 1x MezIO® expansion port for Neousys MezIO® modules |
| USB2.0 | 1x USB 2.0 port with Type-A connector (internal, Nuvo-11006E/ LP) |
| Power Supply | |
| DC Input | 1x 3-pin pluggable terminal block for 8V to 48VDC DC input with optional ignition power control |
| Remote Ctrl. & LED Output | 1x 10-pin (2x5) wafer connector for remote on/off control and status LED output |
| Mechanical | |
| Dimension | 240 mm (W) x 225 mm (D) x 90 mm (H) (Nuvo-11000E series) 240 mm (W) x 225 mm (D) x 79 mm (H) (Nuvo-11000LP series) |
| Weight | 3.58 kg (Nuvo-11000E Series) 3.36 kg (Nuvo-11000LP series) |
| Mounting | Wall-mount (standard) or DIN-rail mount (optional) |
| Environmental | |
| Operating Temperature | With 35W CPU -25°C to 70°C*/** With 65W CPU -25°C to 70°C*/** (configured as 35W TDP) -25°C to 50°C*/** (configured as 65W TDP) |
| Storage Temperature | -40°C to 85°C |
| Humidity | 10% to 90% , non-condensing |
| Vibration | MIL-STD-810H, Method 514.8, Category 4 |
| Shock | MIL-STD-810H, Method 516.8, Procedure I |
| EMC | CE/FCC Class A, according to EN 55032 & EN 55035 |
* For sub-zero and over 60°C operating temperature, a wide temperature HDD/ SSD/ NVMe is required.
**For 10G LAN, operational up to 60°C ambient.
