| System Core | |
|---|---|
| Processor | Supports Intel® Core™ Ultra 200 series CPU (LGA 1851 socket), 35W and 65W TDP - Intel® Core™ Ultra 9 285/285T - Intel® Core™ Ultra 7 265/265T - Intel® Core™ Ultra 5 245/245T |
| Chipset | Intel® Q870E Platform Controller Hub |
| Graphics | Integrated Intel Xe LPG Graphics |
| AI Engine | Integrated Neural Processing Unit |
| Memory | Up to 128 GB DDR5 6400 SDRAM (two SODIMM slots) |
| AMT | Supports Intel vPro/ AMT 16.0 |
| TPM | Supports dTPM 2.0 |
| I/O Interface | |
| Ethernet | 5x 2.5G Ethernet by I226-IT and 1x 1G Ethernet by I219-LM with screw-lock 1x optional 10GBASE-T Ethernet |
| PoE+ | Optional IEEE 802.3at PoE+ PSE for Port 3 ~ Port 6. 100W total power budget |
| USB 3.2 | 8 x USB 3.2 Gen2 ports |
| Isolated DIO | 4-CH isolated DI and 4-CH isolated DO |
| Video Port (Integrated Graphics) | 1x HDMI™, supporting 3840 x 2160 resolution 2x DisplayPort, supporting 4096 x 2304 resolution |
| Serial Port | 2x software-programmable RS-232/ 422/ 485 ports (COM1/COM2) 2x 3-wire RS-232 ports (COM3/COM4) |
| Audio | 1x 3.5 mm jack for mic-in and speaker-out |
| Storage Interface | |
| SATA HDD | 2x internal SATA port for 2.5” HDD/ SSD installation, supporting RAID 0/1 |
| M.2 | 1x M.2 2280 M key NVMe socket (PCIe Gen5x4) for NVMe SSD |
| Expansion Bus | |
| PCI Express | 1x PCIe x16 slot@Gen4, 16-lanes PCIe signal in Cassette for installing NVIDIA® GPU up to 150W (Max. graphics card dimension is 168 mm(L) x 117 mm(W), dual slot allocation) |
| Mini-PCI Express | 2x full-size mini PCI Express socket |
| Expandable I/O | 1x MezIO® expansion port for Neousys MezIO® modules |
| USB2.0 | 1x USB 2.0 port with Type-A connector (internal) |
| Power Supply | |
| DC Input | 1x 3-pin pluggable terminal block for 8 to 48V DC input, rated current 20A. |
| Remote Ctrl. & LED Output | 1x 10-pin (2x5) wafer connector for remote on/off control and status LED output |
| Mechanical | |
| Dimension | 240 mm (W) x 225 mm (D) x 111 mm (H) |
| Weight | 3.89kg |
| Mounting | Wall-mount (standard) or damping bracket (optional) |
| Environmental | |
| Operating Temperature | With 35W CPU and 150W GPU -25°C to 60°C[1] With 65W CPU and 150W GPU -25°C to 60°C[1] (configured as 35W TDP) -25°C to 50°C[1] (configured as 65W TDP) |
| Storage Temperature | -40°C to 85°C |
| Humidity | 10% to 90% , non-condensing |
| Vibration | Operating, MIL-STD-810H, Method 514.8, Category 4 (with optional damping bracket) |
| Shock | Operating, MIL-STD-810H, Method 516.8, Procedure I (with optional damping bracket) |
| EMC | CE/FCC Class A, according to EN 55032 & EN 55035 |
[1] For sub-zero operating temperature, a wide temperature HDD/ SSD/ NVMe is required.
