| System Core | |
|---|---|
| Processor | Supporting Intel® 14th-Gen Core™ CPU (LGA1700 socket, 65W/ 35W TDP) - Intel® Core™ i9-14900/ i9-14900T - Intel® Core™ i7-14700/ i7-14700T - Intel® Core™ i5-14500/ i5-14400/ i5-14500T - Intel® Core™ i3-14100/ i3-14100T Supporting Intel® 13th-Gen Core™ CPU (LGA1700 socket, 65W/ 35W TDP) - Intel® CoreTM i9-13900E/ i9-13900TE - Intel® CoreTM i7-13700E/ i7-13700TE - Intel® CoreTM i5-13500E/ i5-13400E/ i5-13500TE - Intel® CoreTM i3-13100E/ i3-13100TE Support Intel® 12th-Gen Core™ CPU (LGA1700 socket, 35W/ 65W TDP) - Intel® CoreTMi9-12900E/ i9-12900TE - Intel® CoreTMi7-12700E/ i7-12700TE - Intel® CoreTM i5-12500E/ i5-12500TE - Intel® CoreTM i3-12100E/ i3-12100TE - Intel® Pentium® G7400E/ G7400TE - Intel® Celeron® G6900E/ G6900TE |
| Chipset | Intel® R680E Platform Controller Hub |
| Graphics | Integrated Intel® UHD Graphics 770 (32EU)/ 730 (24EU) |
| Memory | Up to 128GB ECC/ non-ECC DDR5 4800 SDRAM (up to 2x 64GB SODIMM modules) |
| AMT | Supports Intel vPro/ AMT 16.0 |
| TPM | Supports dTPM 2.0 |
| I/O Interface | |
| Ethernet | 2x 2.5G Ethernet by I226-IT and 1x Gigabit Ethernet by I219-LM |
| 10G Ethernet (optional) | 1x 10GBASE-T port by Marvell AQC113CS, supporting NBASE-T (5G/2.5G) and 1000BASE-T (Optional) |
| USB 3.2 | 6x USB 3.2 Gen2x1 (10 Gbps) ports |
| USB 2.0 | 1x USB 2.0 ports (internal for dongle use) |
| Video Port (Integrated Graphics) | 1x VGA connector, supporting 1920 x 1200 resolution, 1x DisplayPort connector, supporting 4096 x 2304 resolution |
| Serial Port | 2x software-programmable RS-232/ 422/ 485 ports (COM1/COM2) |
| Audio | 1x 3.5 mm jack for mic-in and speaker-out |
| Storage Interface | |
| SATA HDD | 1x front-accessible, hot-swappable HDD tray for 2.5" HDD/SSD installation |
| M.2 | 1x M.2 2280 M key socket (PCIe Gen4 x4) for NVMe SSD 1x front-accessible M.2 2280 M key tray (PCIe Gen4 x4) for NVMe SSD (Optional) |
| Expansion Bus | |
| PCI Express | 1x PCIe x16 slot @Gen4, 16-lanes (70 mm slot width) GPU locking bracket for RTX Pro 6000, and selected GPU Cards 3x PCIe x8 slots @Gen3, 4-lanes |
| Mini PCI Express | 2x full-size mini PCI Express sockets with internal SIM sockets |
| M.2 | 1x M.2 2242/3052 B key socket with internal SIM |
| Power Supply | |
| DC Input | 3-pin + 4-pin pluggable terminal block for 9V to 32V DC input with ignition control |
| Mechanical | |
| Dimension | 224 mm (W) x 400 mm (D) x 196 mm (H) (without damping bracket) |
| Weight | 7.1kg |
| Mounting | Wall-mount with damping brackets |
| Environmental | |
| Operating Temperature | With 35W CPU and NVIDIA 600W GPU: -25°C to 60°C [1] With 65W CPU and NVIDIA 600W GPU: -25°C to 60°C [1][2] (with optional fan kit) -25°C to 50°C [1][2] (without optional fan kit) |
| Storage Temperature | -40°C to 85°C |
| Humidity | 10% to 90% , non-condensing |
| Vibration | MIL-STD-810H, Method 514.8, Category 4 (with damping bracket) |
| Shock | MIL-STD-810H, Method 516.8, Procedure I |
| EMC | CE/FCC Class A, according to EN 55032 & EN 55035 |
[1] For sub-zero operating temperature, a wide temperature HDD or Solid State Disk (SSD) is required.
[2] For 65W CPUs, the optional fan kit is recommended for operating at ambient temperatures higher than 50°C.
