Processor

Intel® Skylake Dual-Core i5 / Celeron 3955U

System Memory

DDR4 up to 16GB

OS Support

Microsoft® Windows 7
Microsoft® Windows 8.1
Microsoft® Windows 10
Ubuntu 18.04 LTS
IGEL (thin client solution)

Graphics

Intel® HD Graphics 520

Storage

M.2 SSD up to 512GB (optional)

Wireless Communication

802.11 ac/a/b/g/n + BT 4.0 (optional)

Touch

Project Capacitive Touch / Resistive Touch

Speaker

3W x2

Security

TPM 2.0

Display Size

15.6”

Resolution

1920 x 1080

Max. Colors

262K

Contrast Ratio

500:1

Luminance (cd/m2)

220

USB

USB 3.0 x2, USB 2.0 x2

Video Out

HDMI x1

COM

COM port x1

Ethernet

Gigabit LAN x 2

DC-in

12V DC-in x1

VESA

75/100 mm VESA mount

Operating Temperature

0°C ~ 35°C(32°F ~ 95°F)

Storage Temperature

-20°C ~ 60°C(-4°F ~ 140°F)

Storage Humidity

10%~95%@40°C, non-condensing

Degree of Protection

Front Panel: IP65 ; Rear: IPX1

Dimension

392(L) x 43(W) x 265(H) mm

Net Weight

2.7kg

Packing Size

520(L) x 190(W) x 400(H) mm

Gross Weight

4.7 Kg

Certifications

CE : EN 60601-1-2: 2015 + A1: 2021 ( V4.1),
EN 60601-1: 2007 + A1:2013 +A2:2021 ( V3.2)
EN 55032:2015/A1:2020
EN55035:2017/A11:2020( ITE)
IEC62368-1:2020+A11:2020 ( ITE)
FCC : Part 15B/ Part 18
UL : ANSI AAMI ES60601-1:2005/A1:2012/A2:2021( V3.2)
cUL : CAN/CSA-C22.2 No. 60601-1:14 (IEC 60601-1: 2005+A1:2012+A2:2020,MOD) ( V3.2)
TELEC :JAPAN TELEC
