Processor

Intel® Arrow Lake Core™ Ultra 5 225U

System Memory

DDR5 up to 48GB

OS Support

Microsoft® Windows 11
Ubuntu 24.04 LTS
IGEL (thin client solution)

Storage

m.2 SSD up to 2TB

Wireless Communication

WiFi 6E + Bluetooth 5.3 (optional)
Wifi 7 + Bluetooth 5.4 (optional)

Touch

PCT /AG (optional)

Speaker

3W x2

Trusted Platform Module

TPM 2.0

Security

Smart Card Reader (optional),Imprivata RFID reader (optional),Barcode reader (optional)

Waterproof

Front IP65 ; rear IPX2

Display Size

21.5”

Resolution

FHD 1920 x 1080

Max. Colors

16.7M

Contrast Ratio

3000:1

Luminance (cd/m2)

250

USB

Rear I/O :USB 3.0 x2, USB 2.0 x2 ,USB Type C x1
Front bottom I/O : USB 3.0 x2

Video Out

HDMI 2.1 x1

COM

COM port x2 (3kv isolation optional)

Audio

Combo audio port x1

Ethernet

1.5kv isolated Gigabit LAN x2

DC-in

19V DC-in x1

VESA

75/100 mm VESA mount

Operating Temperature

0°C ~ 35°C(32°F ~ 95°F)

Storage Temperature

-20°C ~ 60°C(-4°F ~ 140°F)

Storage Humidity

10%~95%@40°C, non-condensing

Dimension

510(L) x 78.4(W) x345.8(H)

Package Size

645(L) x 210(W) x 513(H) mm

Gross Weight

11kg(24.3 lbs)

Net Weight

7kg

Certifications

CE: EN 60601-1-2: 2015 + A1: 2021 ( V4.1),
EN 60601-1: 2007 + A1:2013 +A2:2021 ( V3.2)
EN 55032:2015/A1:2020
EN55035:2017/A11:2020( ITE)
IEC62368-1:2020+A11:2020 ( ITE)
FCC : Part 15B/ Part 18
UL: ANSI AAMI ES60601-1:2005/A1:2012/A2:2021( V3.2)
cUL: CAN/CSA-C22.2 No. 60601-1:14 (IEC 60601-1: 2005+A1:2012+A2:2020,MOD) ( V3.2)
TELEC :JAPAN TELEC
