Processor

AMD® EPYC™ 9005 Turin series server 400W CPU, up to 160 cores/
320 threads

Graphics

Silicon Motion SM768

Memory

Up to 384GB ECC DDR5 6000 RDIMM (six RDIMM slots)

TPM

dTPM 2.0

10G Ethernet

2x 10GBASE-T ports with screw-lock by Broadcom 57416,
supporting 10G/1G link speed and RDMA (RoCEv2)

Gigabit Ethernet

1x GbE port with screw-lock by Intel i210 supporting Wake-on-LAN
(WOL)

USB

3x USB 3.2 Gen1 (5 Gbps) ports

Video Port

1x HDMI port via SM768, supporting 1920 x 1080 resolution

Serial Port

1x software-programmable RS-232/422/485 ports (COM1)
3x 3-wire RS-232 ports (COM2/ 3/ 4) or 1x RS-422/ 485 port (COM2)

2x8 Pin Terminal Block

1x Ignition power control
1x Power LED
1x System monitoring MCU RS-232 port
1x System monitoring MCU isolated DO
1x System monitoring MCU isolated CAN 2.0 port

M.2 M

2x M.2 2280 M key socket (PCIe Gen4x4) for NVMe SSD

U.2 NVMe

1x front-accessible 2.5” U.2 tray (up to 15mm height, PCIe Gen3x4)

SlimSAS

1x internal SlimSAS (PCIe Gen3x4) port

PCI Express

2x PCIe x16 slot@Gen5, 16-lane interface for 400W, dual-slot width,
NVIDIA® FHFL GPU card
4x PCIe x16 slot@Gen5, 16-lane interface
1x PCIe x16 slot@Gen5, 8-lane interface

Mini PCI Express

2x full-size Mini PCIe sockets (PCIe + USB 2.0; one with micro-SIM slot)

DC Input

1x 4-pin + 1x 5-pin pluggable terminal block for 9V to 32V DC input[1]

Dimension

444 mm (W) x 388 mm (D) x 130 mm (H)

Weight

12.9 kg (excluding mounting kits)

Mounting

Wall-mount (standard)
Rack-mount (standard)
Damping bracket (standard)

Operating Temperature

-25°C to 60°C
Under continuous 100% CPU and GPU utilization, non-throttling
operation is maintained as follows:
55°C to 60°C: Up to 300W CPU and 200W GPU
45°C to 50°C: Up to 400W CPU and 300W GPU

Storage Temperature

-40°C to 85°C

Humidity

10% to 90%, non-condensing

Vibration

MIL-STD-810H, Method 514.8, Category 4 (Operating)

Shock

MIL-STD-810H, Method 516.8, Procedure I (Operating): 20G,
±X/ ±Y/ ±Z-axes, 3 shocks per direction (18 total shocks)
IEC 60068-2-27:2008 (Operating): 50G, ±Z-axis only, 3 shocks per
direction (6 total shocks)

EMC

CE/ FCC Class A, according to EN 55032 & EN 55035
